•  Sizes : DN15 to DN100.
• Body : Die Cast Aluminium
• End Connections:
• DN15 to DN25 : Rp threaded as per EN 10226/ Flanged
• DN32 to DN50 : Rp threaded as per EN 10226 as per ISO 7005 (PN16) Or ANSI B16.5 ASA 150#RF
• DN65 to DN100: Flanged as per ISO 7005 (PN16) Or ANSI B16.5
• Pmax: 0.5 Bar, 1 Bar, 5 Bar & 6 Bar version available
• Suitable for Natural Gas, LPG, Propane and other dry and non aggressive gases of the 3 families. As per EN437:2003
• Versions available for Biogas and other select Gases on request.
• Environment temperature rating : -20 to +70°C

Product conformance:

• EC certified according to EN 88
• In conformity with the 90/396/EEC Directive (Gas Directive)
• In conformity with the 97/23/EC Directive (PED Directive)
• In conformity with the 94/9/EC Directive (ATEX Directive)
